12kV ฯ-Type Touchable Front / Rear Connector
- 12kV ฯ-type touchable connector designed for fully insulated and screened medium voltage cable connection systems.
- Available as front connector and rear connector configurations for 630A separable cable accessory systems.
- Designed for applications including ring main units, switchgear and compact medium voltage distribution equipment.
- The touch-proof structure helps provide a safer connection arrangement compared with exposed connection systems.
- Correct selection requires confirmation of equipment interface, cable dimensions and matching separable connector components.
Fully Insulated Touchable Connection for 12kV 630A Medium Voltage Systems
Medium voltage connection systems used in compact switchgear and ring main units require accessories that combine electrical insulation, shielding and equipment compatibility. The 12kV ฯ-type touchable connector is designed for applications where a fully insulated separable connection is required.
RIKI HY ฯQJT-12/630 and HY ฯHJT-12/630 connectors provide front and rear connection options for 630A medium voltage systems. The correct configuration depends on equipment interface design and the required cable connection arrangement.
Touch-Proof Design for Compact Distribution Equipment
The fully insulated structure helps provide a safer connection environment for medium voltage equipment. It is suitable for applications where exposed conductive connection points need to be avoided.
Front and Rear Connector Options for System Expansion
The front and rear connector versions allow different connection arrangements within compact medium voltage equipment. Buyers should confirm the required connector position and matching components before ordering.
630A Separable Connector for RMU and Switchgear Applications
The 12kV touchable T connector is designed for 630A separable cable connection systems used in ring main units, switchgear and medium voltage distribution equipment.
Interface Matching Is Critical Before Selection
Selection should consider equipment bushing type, cable specifications and complete connection system requirements. A connector with the correct voltage rating may still require different components depending on the equipment design.
12kV ฯ-Type Touchable Connector Specifications
| Product Type | Touchable Front / Rear Connector |
|---|---|
| Model | HY ฯQJT-12/630 / HY ฯHJT-12/630 |
| Voltage Class | 12kV |
| Rated Current | 630A |
| Product Structure | ฯ-Type Separable Connector |
| Insulation Type | Fully Insulated and Screened |
| Application | Ring Main Unit, Switchgear, Medium Voltage Distribution Equipment |
| Connection Type | Front Connector / Rear Connector |
Frequently Asked Questions (FAQ)
What is a 12kV touchable T connector used for?
A 12kV touchable T connector is used for fully insulated separable cable connections in medium voltage equipment such as ring main units, switchgear and distribution systems where a screened connection structure is required.
What is the difference between a front connector and rear connector?
The front and rear connector versions are designed for different equipment connection arrangements. The correct selection depends on the switchgear structure and required cable connection layout.
Why choose a fully insulated separable connector system?
A fully insulated separable connector provides a protected connection structure that helps reduce exposure of conductive parts in medium voltage equipment installations.
What information is required before ordering a 630A separable connector?
Buyers should provide voltage level, equipment interface type, cable specifications, connector position requirement and quantity to confirm the suitable configuration.
Applications of 12kV Touchable T Connector in Medium Voltage Systems
Ring Main Units
Used in RMU equipment requiring compact fully insulated medium voltage cable connections.
RMU ยท 12kV ยท 630A
Medium Voltage Switchgear
Suitable for switchgear systems where screened separable cable accessories are required.
Switchgear ยท Separable Connection
Medium Voltage Distribution
Applied in distribution systems requiring insulated and touch-safe cable connection solutions.
Distribution ยท Cable Accessories
Medium Voltage Projects
Used for B2B projects requiring matched cable accessories and equipment interface solutions.
OEM Supply ยท Project Application
